A Single System Delivers Hot Water And Interior Heating
Downsizing Doesn’t Mean Compromising Comfort
The Aqua-Hot AH200 heater is a compact hydronic heating system (heating with hot water) system that circulates heated
fluid through a closed-loop pex-tube circuit. This is extremely efficient,
especially compared to forced-air ducting. This approach also allows you
design choices for in-floor radiant heating, heat exchangers or a
combination of the two.
Aqua-Hot mounted heat exchangers gently move heat into the living space.
In-floor installations conduct the heat from the entire floor, softly radiating it
into the room.
Hot water is supplied from a storage tank, well or city water system and connected
to the Aqua-Hot water circuit entry. Water is then heated and pumped
to the taps. Hot. Fast. Constant.
- - Propane, natural gas or diesel systems; also available with an electric element
- - Burner runs only when necessary
- - 12-volt DC operation capable
- - Thermostat controlled
- - 40,000 Interior Heating BTUs
- - Continuous hot water at 120ºF 1.5GPM
Aqua-Hot Comfort Zones
Continuous Hot Water
You’ll never run out of hot water for showers, laundry or dishes.
Flow rates are comparable to standard residential delivery rates
with no recovery time.
Individually controllable heat exchangers gently circulate heat
where you want it and when you need it. No drafts. No breezes.
Aqua-Hot systems are certified for safe use in households,
mobile homes and recreational vehicles in the United States
and Canada by ETL Intertek Testing Services.
With the Aqua-Hot system, air is warmed as it moves across the heat
exchangers and circulates into the living space with gentle, warm, even
heating. You won’t feel the evaporative skin cooling associated with hot
air blowing from gas furnaces, or hot and cold spots with electric space
heaters or fireboxes.
How To Design Your AH200 Hydronic Heating System Installation
Work with your builder to design an Aqua-Hot system into your tiny home
space. Make sure to account for window and door positions, home
insulation, room volume and floor type of your living space. The AH200
lets you position up to five heat exchangers, with individual control,
or choose in-floor heating. You can even combine the two.
Domestic hot water system distribution can be designed as a traditional
trunk-and-branch system, as well as a home-run manifold or sub-manifold
system that saves water and energy.
